Transparent CNC
Trainer Kit
Features:
AC servo drives
AC variable speed spindle motor
Hardended and ground ball - screws
Centralised automatic lubrication
Basic coolant system
Telescopic covers and bellow on Z-axis
Full Machine guard
Manual pulse generator
Machine Specifications:
X – Axis Travel
: 250 mm
Y – Axis Travel
: 200 mm
Z – Axis Travel
: 200 mm
Table Size
500 x 250 mm
T Slot
: 3 X 14 X 80
Distance From floor to table top
: 840 mm
Maximum Load on table
: 60 – 6000 RPM
Rapid Traverse X,Y and Z Axes
: 25/25/18 M/min
Cutting Feed
: 0 -5000 mm/min
Automatic Tool Changer
: 8 No.s
Spindle Power
: 5.5/3.7 KW
Feed Motor
: 3.5/3.5/7 Nm
Guideway
: Linear(X,Y,Z)
Controller
: Siemens/Fanuc/Industrial Controller
