CNC DRILL TRAINERS
Features:
CNC Drilling Machine With X, Y & Z Axes Stepper Motor Driven.
All Axes Fitted with ball screws.
Drilling Head with travel up and down for drilling
Variable speed D.C Drive for spindle
The CNC control will have normal drilling, peck drilling & PCD drilling cycles.
Rigid structure to absorb vibrations
Controller with power drive
Computer interface system for communication between controller and PC.
Power full operating software with online and offline simulation.
Machine Specifications:
Model
: VDM - 200
Table Length X Width
: 450 X 250 mm
Table Clamping Area
: 400 X 250 mm
Table T Slot
: 10 mm Slots width
Axis Travel
:
Longitudinal Traverse
: 200 mm
Cross Traverse
: 200 mm
Vertical Traverse
: 150 mm
Spindle
:
Speed
: 200 mm - 1500 RPM
Power
: 1H P D C Motor
CNC System
Axis Control
: 3 AXIS ( X, Y & Z Simultaneously)
Lease Count
: 0.015 mm
Accuracies, Resolution
: 0.015 mm
Rapid Traverse Rate Z Axis
: 8 m/min
Rapid Traverse Rate
: 300 mm / min.
Feed Rate
: 1 - 300 mm / min. ( X & Y Axis)
Interpolation
: Linear
Command Type
: Absolute & Incremental
Date Entry
: Key Board
Backlash Compensation
: upto 2 mm, on each Axis
Axis Driver
: D.C Stepper Motors for all the Axis
Programming
: G, M, S, X, Y, & Z Codes
Canned Cycles
: Drilling, Peck Drilling & PCD Drilling
Co-ordinates
: ISO Code programming, point to point movement
Electrical Power
: 230 V, 50 Hz
Accessories
: Machine vice 100 mm with opening drill chuck Collates Dia. 3,4,5,6,8,10,& 12 mm
