CNC Mill Trainers with Industrial
Controller
Features:
Rugged Machine with Ground Bed
12 Station Programmable Turret
Fully Enclosed Working Area
Programmable Spindle
Manual Pulse Generator (Optional)
FMS & CIM Compatibility
Hydraulic Chuck (Optional)
Auto Door (Optional)
Machine Specifications:
Model
VMM-IA- 200
X – Axis Travel
: 250 mm
Y – Axis Travel
: 175 mm
Z – Axis Travel
: 200 mm
Table Size
: 500 x 200 mm
Spindle Nose to Table Top
: 40 – 190 mm
Spindle to Column
: 110 mm
Spindle Inside Taper
: BT 30 / ISO 30
Maximum Tool Size
: Diameter 12 mm, Length 70 mm
Spindle Motor
: 2 H.P DC Motor with 3000 RPM
Resolution
: 0.005 mm
Repeatability
: ± 0.01 mm
Automatic Lubrication Points
: Provided
Interpolation
: Linear, Circular
Programmable Feed Rate
: ø - 800 mm/Min.0- 800 mm/Min.( X,Y,Z )
Rapid Feed Rate
: ø - 1200 mm/Min.( X,Y,Z )
Control System
: Siemens / Equivalent Industrial Controller
Automatic Tool Changer
: 12 Station ( Pneumatic )
Lubrication
: Centralized ( Programmable )
Axis Motor
: Stepper / Servo Motor
Mains Supply
: 230 V AC, 1 Phase For Machine and 3 Phase 415 V AC for ATC
Machine Dimensions
: Approx. 1200 x 1200 x 1800 mm
Total Weight
: Approx. 1200 Kg.
